ECO-DIM.03 PRO LED dimmer universal 0-700W (RLC)

✓ 0-700W LED
✓ Universal: phase on/phase off (RLC)
✓ DEKRA certified
✓ 5-year warranty
✓ Made of recycled plastic
✓ Replaceable fuse + additional fuse

*The PRO line is only available via an electrical wholesaler

✓ Suitable for all known brands of cover material
✓ Small mounting depth
✓ Optimal dimmability & light stability
✓ MIN & MAX adjustment
✓ Protection against overload & overheating
✓ Silent dimming
✓ Optimal ventilation
✓ Suitable for two-way switching & cross switching
✓ Suitable for all dimmable LED lamps
✓ Soft-start system
✓ Supplied with fittings

General information

Article number: ECO-DIM.03 PRO
Type led dimmer: Trailing Edge & Leading Edge / R,L,C
Power: 0-700W RLC LED
Control: Push/ turn
Packaging: Individually packed

Suitable marks cover material

• Berker by Hager
• Busch-Jaeger
• Gira
• JUNG
• Kopp
• Merten by Schneider 51xx and System M
• Niko xxx-31003 (provided the use of Niko adapter) and xxx-31000
• PEHA

Not suitable:

• Busch-Jaeger 6540-7
• Merten D-Life
• Niko PR20
• Dimmer knob with D-shape hole, such as Wintop, Plieger, GAMMA Everest

Suitable lamps

Led lamps 230V (0-700W)
Incandescent lamps (max. 5-800W)
Halogen lamps 230V (max. 5-800W)
Low-voltage lamps with electronic transformer, such as LED lamps with transformer (max. 5-800W)
