ECO-DIM.04 PRO LED dimmer universal 0-200W (RC)

✓ 0-200W LED
✓ DEKRA certified
✓ 5-year warranty
✓ Made of recycled plastic

*The PRO line is only available via an electrical wholesaler

✓ Trailing edge (RC)
✓ Suitable for all known brands of cover material
✓ Small mounting depth
✓ Optimal dimmability & light stability
✓ MIN adjustment & automatic MAX detection
✓ Strong metal pin
✓ Overload & overheating protection
✓ Silent dimming
✓ Optimal ventilation
✓ Suitable for two-way switching & cross-switching
✓ Soft-start system
✓ Supplied with fittings

General information

Article number: ECO-DIM.04 PRO
LED dimmer type: Trailing Edge / Phase cut / RC
Power consumption: 0-200 Watt RC LED
Control: Push/ turn
Packaging: Individually packed

Suitable cover brands

• Berker by Hager
• Busch-Jaeger
• Gira
• JUNG
• Kopp
• Merten by Schneider 51xx and System M
• Niko xxx-31003 (if using Niko adapter) and xxx-31000
• PEHA

Not suitable:

• Busch-Jaeger 6540-7
• Merten D-Life
• Niko PR20
• Dimmer knob with D-shaped hole, such as Wintop, Plieger, GAMMA Everest

Suitable lamps

Led lamps 230V* (0-200W)
Incandescent lamps (5-250W)
Halogen lamps 230V (max. 5-250W)
Low-voltage lamps with electronic transformer, such as LED lamps with transformer (max. 5-250W)

*Provided the lamps operate on a phase cut / trailing edge LED dimmer.
